SMILE-T10-HV

This 10kW energy storage system comes with 8.2kWh high voltage battery modules. The high-voltage storage technology will squeeze every kWh from the solar panels. This three-phase warrior has max. PV input power with 16kW, which can maximize the potential of your system.

Energy Independence
Stores excess solar energy to power your home at night or during peak-rate hours and provides backup power in the event of a grid interruption
High Efficiency
Minimizes energy waste day and night with High-voltage storage technology
Boost Profits with STC Subsidy
Supports max. 16kW PV input power
Three-phase Output
Provides three-phase backup power
SMILE-T10-HV

This 10kW energy storage system comes with 8.2kWh high voltage battery modules. The high-voltage storage technology will squeeze every kWh from the solar panels. This three-phase warrior has max. PV input power with 16kW, which can maximize the potential of your system.

Energy Independence
Stores excess solar energy to power your home at night or during peak-rate hours and provides backup power in the event of a grid interruption
High Efficiency
Minimizes energy waste day and night with High-voltage storage technology
Boost Profits with STC Subsidy
Supports max. 16kW PV input power
Three-phase Output
Provides three-phase backup power
Product Introduction

Phase:Three Phase
Nominal Output Power:10 kW
Max. PV Input Current:26 A / 26 A
Max. PV Input Power:16 kWp
MPPT Number:2
Max. Input Strings Number per MPPT:2+1
Capacity Range:8.2 - 49.2 kWh

Battery Compatible Model
Battery Technical Specification

SMILE-BAT-8.2PH

SMILE-BAT-8.2PH

Module Model
SMILE-BAT-8.2PH
Energy Capacity
8.2 kWh
Modules Connection
1 - 6 in parallel
Max. Charging / Discharging Current
32 A / 32A
Operating Temperature Range
0 ~ 50℃(Charge); -10 ~ 50℃(Discharge)
IP Protection
IP65
Dimension (W x D x H)
580 x 230 x 730 mm
Weight
71 kg
Product Documents

Click any of the categories to find the documents in our online service center.

System Datasheet Battery Datasheet
Monitoring App User Manual
Installation Manual
Saftey Datasheet
