5–20 kW Power Flexibility
Comprehensive three-phase power range for different household energy needs.
Certified Safety
TÜV-certified and tested to UL 9540A standards for enhanced system protection.
VPP Integration Ready
Integrated with 30+ VPP platforms for smarter energy participation.
UPS Backup Switching
Seamless transition to backup power during outages and grid interruptions.
x
Product Introduction
- Nominal Output Power: 5/10/15/20 kW
- Max. PV Input Current:
16 A / 16 A / 16 A （SMILE T5/T10）
18 A / 18 A / 18 A （SMILE T15/T20） - Max. PV Input Power:
10 kWp/20 kWp (SMILE T5/T10)
40 kWp (SMILE T15/T20) - Capacity Range:
9.3 - 55.8 kWh （SMILE T5/T10）
18.6 - 55.8 kWh（SMILE T15/T20） - Backup: UPS
- Phase: Three Phase
- Inverter Type: Hybrid Inverter
x
Product Documents
Click any of the categories to find the documents in our online service center.
