SMILE-G3-B5
This battery storage system comes with a 5kW single-phase AC-coupled inverter and 10kWh battery modules. It is quite suitable for scenarios where solar panels and solar inverters have been installed and helps consumers achieve energy independence.
Maximise Solar Energy Usage
Stores excess solar production for reliable power day and night
Power For Emergencies
Provides backup power in the event of a grid interruption
All-in-One System
Aesthetically pleasing and practical all-in-one design
Good Compatibility
Compatible with all the existing solar inverter brands in the Australian market
Built-in Changeover Switch Functionality
Ensures backup circuit is working when the inverter fails
SMILE-G3-B5
This battery storage system comes with a 5kW single-phase AC-coupled inverter and 10kWh battery modules. It is quite suitable for scenarios where solar panels and solar inverters have been installed and helps consumers achieve energy independence.
Maximise Solar Energy Usage
Stores excess solar production for reliable power day and night
Power For Emergencies
Provides backup power in the event of a grid interruption
All-in-One System
Aesthetically pleasing and practical all-in-one design
Good Compatibility
Compatible with all the existing solar inverter brands in the Australian market
Built-in Changeover Switch Functionality
Ensures backup circuit is working when the inverter fails
Product Introduction
Phase:Single Phase
Nominal Output Power:5 kW
Capacity Range:10.1 - 60.5 kWh
Backup:UPS
Battery Compatible Model
Battery Technical Specification
-
Module ModelSMILE-G3-BAT-10.1P
-
Energy Capacity10.1kWh
-
Modules Connection1 ~ 6 in Parallel
-
Max. Charging/Discharging Current60/60A
-
Operating Temperature Range-10 °C ~ 50 °C
-
IP ProtectionIP65（Outdoor）
-
Dimension (W x D x H)610 x 212 x 793 mm
-
Weight90 kg
Product Documents
Click any of the categories to find the documents in our online service center.
